Zaozhuang Sunweigh anticorrosive automatic bag machine SW-ABF become the first in China
Zaozhuang Sunweigh Technology Co., Ltd. developed and produced automatic bag feeding machine SW-ABF can realize the automatic finishing of packaging bags, automatically pick up woven bags, Kraft paper bags and open the mouth of the bags. The robot will automatically cover the packaging bags at the material mouth of the packaging machine. Finally, the bag clamps the package to complete the whole bag process. Since the automatic bagging machine is designed with stainless steel anti-corrosion material, the automatic bagging machine can be used in the corrosive production environment to ensure the normal and smooth operation of the production.
Working principle of automatic bag feeding Machine
1. Packaging bag separation. First, the suction tray absorbs the empty bag from the top, the lifting cylinder pulls the bag up, the transfer device leads the bag forward to the open belt position, and completes the process of single packing to separating the package from the stack;
2, Open the bag. When the bag reaches the designated position, the upper and lower suckers press the bag at the same time, pull the bag in two directions, grasp the bag hand into the bag, grab the upper and lower sides of the bag at the same time, and complete the opening and grasping of the bag;
3, Grab the bag hand to pick up the bag, the bag mouth will be large, larger than the size of the packaging machine, turn the rocker arm up, The package bag is placed into the discharge port, the bag is bagged, and the bag is loaded.
4.After the bag is placed into the discharge port, the front and rear clamping cylinder clamps the package bag under the control of the output signal of the controller, and the clamping signal is transmitted to the master control instrument at the same time, After receiving the signal, the instrument fills the material into the packing bag and completes the automatic packing process.
The function characteristic of the automatic bagging machine is
1, The automatic bagging machine can realize the separation of the packing bag automatically, the empty bag can be picked up automatically;
2, Completely simulate the human hand function, dexterous intelligence;
3, Configure the dust removal device, the green environmental protection does not pollute;
4, The bag speed is fast, Automatic intelligent bag feeding;
5, Bag Bagging neatly without fold;
6, All stainless steel design, anti-corrosion design
.
-
You may be interested in: changing semi-automatic packaging machine full-automatic packaging machine
Recommended solution: automatic bagging machine high automatic palletizer
