Woven Bag Vertical Full-automatic Packaging Machine SW-ABF-800

     SW-ABF-800 vertical full-automatic packaging machine for woven bags is a vertical blanking full-automatic packaging machine developed and produced by Zaozhuang Sunweigh Technology Co., Ltd. The full-automatic packaging machine is mainly used for full-automatic packaging of woven bags and kraft paper bags. The vertical full-automatic packaging machine for woven bags adopts gravity feeding mode according to the properties of granular materials, screw feeding mode for powder materials and belt feeding mode for mixed materials. The correct feeding method can effectively prevent the equipment from jamming and sticking due to the unsmooth feeding of materials, thus affecting the packaging efficiency. The full-automatic packaging machine can be widely used in the full-automatic packaging of grain, feed, starch, food, fertilizer, chemical industry, medicine, briquette and other materials.

Introduction of Vertical Fully Automatic Packaging Machine for Woven Bags

The full-automatic packaging machine mainly comprises a material bin, an electromagnetic valve, a material feeding weighing device, a material discharging opening bag clamping, an automatic bag feeding machine, a folding machine, a seam machine and a conveyor. The material is stored in the material storage, the electromagnetic valve controls the inlet and outlet of the material, the feeding device feeds the material to the weighing place, the automatic bagging machine automatically covers the packaging bag at the lower material opening, the weighing system automatically fills the weighed material into the packaging bag, the conveyor transports the packaging bag to the hemming machine for hemming and seaming, and the whole process is completed independently by the full-automatic packaging machine without the participation of workers.

Functional Characteristics of Vertical Full - automatic Packaging Machine for Woven Bags

SW-ABF-800 vertical full-automatic packaging machine for woven bags adopts various feeding modes, PLC control system, automatic metering, folding, sewing and packaging of various materials. Full touch screen design, simple operation, convenient for customers to use; The complete set of equipment of the full-automatic packaging machine has complete automatic detection procedures, automatic deviation correction, prompt automatic fault detection and convenient maintenance. The operation of the equipment is personalized without manual participation, and the fault automatic alarm prompts the operator of the fault location, fault phenomenon and fault detection and treatment method.

Technical Parameters of Vertical Fully Automatic Packaging Machine for Woven Bags

Packing range: 20 - 50kg bagged products;
Packaging materials: paper bag, woven bag ( coated film ), double-layer composite bag;
Packaging speed: 200 - 1200 packs / hour ( packaging speed varies according to materials );
Packaging accuracy: 0.2%;
Packaging Material: Different feeding methods can be selected according to different materials. Can package granular materials, powder materials, flake or mixed materials;
Compressed air: 0.4 ~ 0.8 MPa, maximum air consumption 1.6 m³/min；;
Power supply: 6.2Kw AC380V±10% 50Hz.
